Single Loop Detector EX-LD-500
Features
- Industrial grade design
- 10 sensitivity levels are adjustable.
- Supports multi-output ports
- Fault self detected function
- Realized barrier close automatically after car pass
- Supports to connect 2 loop
Specification
- Type: EX-LD-500(Single channel)
- Operating temp.: -30℃ ~ +75℃
- Storage temp.: -40℃ ~ +85℃
- Relative humidity: ≤95%
- Shell: PC + ABS engineering plastics
- Installation: DIN rail
- Dimensions: 110×60×100 mm (L×W×H)
- Net Weight: 400g
- Operating voltages: AC220V±10%
- Power consumption:<5W
- Relay output: DC24V /3A
- Frequency range:20kHz ~ 170kHz
- Reaction time:20 ms
- Sensitivity:10 grades adjustable
- Loop inductance: Ideal 100µH~300µH Max 50µH~1000µH
- Loop Wire: Max 100m, twisted at least 20 times per meter, total resistance <10 Ohm
- Reaction Time: 20ms
- Sensitivity:10 levels adjustable
- Output Delay: 0-4.5s adjustable
- Net Weight: 400g
- Operating voltages:AC220V±10%
- Power consumption:<5W
- Relay output:DC24V /3A
- Sensitivity:10 levels adjustable
- Output Delay: 0-4.5s adjustable
- Net Weight: 400g
- Operating voltages:AC220V±10%
- Power consumption:<5W
- Relay output:DC24V /3A
