Wiegand 2 Doors IP Access Controller EX-AS02Ⅱ
Wiegand 2 Doors IP Access Controller EX-AS02Ⅱ
Free SDK is available.
Excelsoo Door Access Controllers offer users various functions of access control. With its high adaptability, the device is suitable for a range of different application scenarios and can be integrated with various other devices, such as card readers, locks, or push buttons, to satisfy any user's unique requirements.
- Can Control 2 doors, open the door by reading card, get outdoor by exit button or by reading card;
- User capacity: 40,000 user, offline record capacity:100,000;
- Auto open/close at any pre-set time during any day. Support "who" can enter which door at a certain time, authorized access control;
- The record is never lost in case of power failure. High-speed flash memory design, never lost;
- TCP/IP Network communication;
- Software supportable database: access & SQL server. Support win7/win8/win10 32/64 bit.
TCP/IP Access Controller | |
Model | EX-AS02II |
Photo | |
Door | 2 Doors |
Function Description | Wiegand Reader * 4 Door Button * 2 Electric Magnetic Lock* 2 |
Communication | TCP/IP |
Size | 21.9 * 12.2 * 3.4MM (H*W*T) |
Power | 12V DC 4-7A |
Power Consumption | <200mA |
Input Reader | Wiegand 26/34 bit |
Door Open Delay | 1-600S adjustable |
Max. QTY in Network | Unlimited |
Working Temperature | -40 ~ 70℃ |
Working Humidity | 10-90%RH, No Condensation |
User | 40,000 |
Offline Record | 100,000 |
Power Fail Safeguard | High-speed flash memory design, never lost. |
Reader Distance | Max. 100, optimal 80m |
Matching Power Box | |
Model | PBX01 |
Photo | |
Size (mm) | 280 * 120 * 380 (W*T*H) |
Material | 1.2mm cold rolled sheet |
Power | Input: 100-240V AC, 50/60Hz, 1.0A Output: 12V DC, 3A |
Wiegand 2 Doors IP Access Controller EX-AS02II
- Wiegand Reader * 4
- Door Button * 2
- Electric Magnetic Lock* 2
- TCP/IP Network communication
- Door Open Delay: 1-600S adjustable
- User: 40,000
- Offline Record: 100,000
- Door Button * 2
- Electric Magnetic Lock* 2
- TCP/IP Network communication
- Door Open Delay: 1-600S adjustable
- User: 40,000
- Offline Record: 100,000
