Parking Counting System Controller PCS-300

Parking Counting System Controller PCS-300

An important integral part of the parking guidance system

Parking Counting System Controller PCS-300 is used in the networking of the parking guidance system, connected to the parking space detectors, guidance screens, etc., to complete the work of data collection, reporting, and downloading the commands and data of the main controller. The location parking guidance system can effectively guide and manage the parking vehicles entering and exiting the parking lot. It is a powerful supplement to the parking lot management system and constitutes a more intelligent parking lot management system.

Excelsoo Parking Counting System Controller PCS-300

Key Features:


  • Detect whether there is a vehicle passing by, and recognize the direction of the vehicle automatically;
  • Set or modify the total number of parking spaces and the available lots in a certain area;
  • Calculate and display the available lots in the area;
  • Support data collection and correct display results;




Input Power AC110/220V ± 10% 50/60Hz
Language CN/EN
Operating Temperature -40℃~+85℃
CAN Interface Full duplex, safe electrical isolation, communication speed 10Kbps, communication distance up to 5km or more
RS485 Interface Half duplex, baud rate 9600bps (8N1)
TCP Interface Full duplex, 100Mbps
Detection Sensitivity 0~9 levels adjustable
Max. Detected Signal Exist Time 3-255S Adjustable
Loop Induction Range 80-300uh
Applicable Vehicle Speed 5~60km/h
Conditions Of Use Only for single lanes with a road width of 2 to 4 meters

Parking Counting System Controller PCS-300Parking Counting System Controller PCS-300

- Communication: CAN Bus;
- Size: 350*120*420mm(W*T*H)
- Shell material: gray cold steel paint
